TP-LINK JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+ TL-SG2210P

Professional 10-Port Gigabit Smart Switch with 8-Port PoE+

Specs

HARDWARE FEATURES

• Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
• Interface: 8 x 10/100/1000Mbps RJ45 Ports, 2 x 1000Mbps SFP Slots (Auto-Negotiation/Auto MDI/MDIX)
• Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), 100BASE-TX/ 1000Base-T: UTP category 5, 5e or above cable (maximum 100m), 1000BASE-X: MMF, SMF
• Fan Quantity: Fanless
• Power Supply: 100~240VAC, 50/60Hz, External Power Adapter(Output: 54VDC/ 1.3A)
• Power Consumption:10.3W (without POE device connected), 76.5W (with 61W POE devices connected)
• PoE Ports (RJ45): Standard: 802.3af/at compliant, PoE Ports: 8 Ports, Power Supply: 61 W*
• Dimensions ( W x D x H ): 8.2 x 4.9 x 1.0 in. (209 x 126 x 26mm)
• Mounting: Desktop / Wall-Mounting
• Max Power Consumption: V3.2: 76.5 W (220 V/50 Hz) (with 61 W PD connected); 10.3 W (220 V/50 Hz) (no PD connected), V4: 74.4 W (220 V/50 Hz) (with 61 W PD connected), V5: 77.8 W (110 V/60 Hz) (with 61 W PD connected)
• Max Heat Dissipation: V3.2: 261.02 BTU/hr (220 V/50 Hz) (with 61 W PD connected); 35.14 BTU/hr (220 V/50 Hz) (no PD connected), V4: 253.89 BTU/hr (220 V/50 Hz) (with 61 W PD connected), V5: 265.3 BTU/hr (110 V/60 Hz) (with 61 W PD connected)

PERFORMANCE

• Switching Capacity: 20 Gbps
• Bandwidth/Backplane: 20 Gbps
• Packet Forwarding Rate: 14.88 Mpps
• MAC Address Table: 8K
• Packet Buffer Memory: 4.1 Mbit
• Jumbo Frame: 9 KB

SOFTWARE FEATURES

• Quality of Service: 802.1p CoS/DSCP priority, 8 priority queue,  Priority Schedule Mode (Strict Priority, Weighted Round Robin), Queue Weight Config, Bandwidth Control (Port/Flow based Rating Limit), Smoother Performance, Storm Control (Multiple Control Modes(kbps/ratio), Broadcast/Multicast/Unknown-Unicast Control)
• L2 and L2+ Features: 16 IP Interfaces (Support IPv4/IPv6 Interface), Static Routing (32 IPv4/ IPv6 Static Routes), DHCP Server, DHCP Relay (DHCP Interface Relay, DHCP VLAN Relay), DHCP L2 Relay, Static ARP, Proxy ARP, Gratuitous ARP, Link Aggregation (Static link aggregation, 802.3ad LACP, Up to 8 aggregation groups and up to 8 ports per group), Spanning Tree Protocol, Loopback Detection, Flow Control (802.3x Flow Control). Mirroring (Port Mirroring, CPU Mirroring, One-to-One, Many-to-One, Flow-Based, Ingress/ Egress/ Both), Device Link Detect Protocol (DLDP), 802.1ab LLDP/ LLDP-MED
• Advanced Features: Automatic Device Discovery, Batch Configuration, Batch Firmware Upgrading, Intelligent Network Monitoring, Abnormal Event Warnings, Unified Configuration, Reboot Schedule
• VLAN: VLAN Group (Max. 4K VLAN Groups), 802.1Q tag VLAN, MAC VLAN, Protocol VLAN, GVRP, Voice VLAN
• Access Control List: Support up to 230 entries, Time-Range, Time-based ACL, MAC ACL (Source MAC, Destination MAC, VLAN ID, User Priority, Ether Type), IP ACL (Source IP, Destination IP, IP Protocol, TCP Flag, TCP/UDP Source Port, TCP/ UDP Destination Port, DSCP/ IP TOS), IPv6 ACL, Combined ACL, Rule Operation (Permit/ Deny), Policy Action (Mirror, Rate Limit, Redirect, QoS Remark), ACL Rules Binding (Port Binding, VLAN Binding)
• Security: AAA, 802.1X (Port based authentication, MAC (Host) based authentication, Authentication Method includes PAP/ EAP-MD5, MAB, Guest VLAN, Support Radius authentication and accountability), IP/IPv6-MAC Binding, IP Source Guard (253 Entries, Source IP+Source MAC), IPv6 Source Guard (183 Entries, Source IPv6 Address+Source MAC), DoS Defend, Static/ Dynamic/ Permanent Port Security, Broadcast/ Multicast/ Unicast Storm Control, Port Isolation, Secure web management through HTTPS with SSLv3/TLS 1.2, Secure Command Line Interface (CLI) management with SSHv1/SSHv2, IP/ Port/ MAC based access control
• IPv6: IPv6 Static Routing and ACL, IPv6 Dual IPv4/IPv6, IPv6 Interface, Multicast Listener Discovery (MLD) Snooping, IPv6 neighbor discovery (ND), Path maximum transmission unit (MTU) discovery, Internet Control Message Protocol (ICMP) version 6, TCPv6/UDPv6, IPv6 applications (DHCPv6 Client, Ping6, Tracert6, Telnet(v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/ Https, IPv6 TFTP)
• Management: Web-based GUI, Command Line Interface (CLI) through telnet, SNMPv1/ v2c/ v3, SNMP Trap/ Inform, RMON (1,2,3,9 groups), SDM Template, DHCP/ BOOTP Client, Dual Image, Dual Configuration, CPU Monitoring, Cable Diagnostics, EEE, SNTP, System Log
• MIBs: MIB II (RFC1213), Bridge MIB (RFC1493), P/ Q-Bridge MIB (RFC2674), Radius Accounting Client MIB (RFC2620), Radius Authentication Client MIB (RFC2618), Remote Ping, Traceroute MIB (RFC2925), Support TP-Link private MIBs, RMON MIB(RFC1757, rmon 1,2,3,9)

MANAGEMENT

• Omada App: Yes, through Omada Cloud-Based Controller (Not Supported by TL-SG2210P v4), OC300, OC200, Omada Software Controller
• Centralized Management: Omada Cloud-Based Controller (Not Supported by TL-SG2210P v4), Omada Hardware Controller OC300, Omada Hardware Controller OC200, Omada Software Controller
• Cloud Access: Yes, through Omada Cloud-Based Controller (Not Supported by TL-SG2210P v4). OC300, OC200, Omada Software Controller
• Zero-Touch Provisioning: Yes. Requiring the use of Omada Cloud-Based Controller (Supported by TL-SG2210P v3.2, v5 and above, while is not supported by TL-SG2210P v4)
• Management Features: Web-based GUI, Command Line Interface (CLI) through telnet, SNMPv1/ v2c/ v3, SNMP Trap/ Inform, RMON (1,2,3,9 groups), SDM Template, DHCP/BOOTP Client, Dual Image, Dual Configuration, CPU Monitoring, Cable Diagnostics, EEE, SNTP, System Log

OTHERS

• Package Contents: TL-SG2210P, Power Adapter, Installation Guide, Rubber Feet
• Operating Temperature: 0℃~40℃ (32℉~104℉);
• Operating Humidity: 10%~90% non-condensing
