TP-LINK 9-Port 10/100Mbps Desktop Switch With 8-Port PoE+, LS109P

• 63 W PoE Budget: Eight 10/100 Mbps 802.3af/at-compliant PoE ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port
• Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas
• PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices
• Traffic Separation for Higher Security: Isolation Mode allows one-click client traffic separation to avoid snooping and tampering, and isolate broadcast storms
• Plug and Play: Simply plug and play for instant connectivity with no configuration required
• Silent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses
• Reliable Hardware Design: Durable metal casing and desktop/wall-mounting design are well-suited for different environments

Specs

HARDWARE FEATURES

• Interface: 9 × 10/100Mbps Ports (8× 10/100 Mbps 802.3af/at PoE+ Ports), Auto Negotiation / Auto MDI/MDIX
• Fan: No
• Network media: 10BASE-T: UTP category 3, 4, 5 cable (Maximum 100m), 100BASE-TX: UTP category 5, 5e cable (Maximum 100m)
• External Power Supply: External Power Adapter (Output: 53.5VDC / 1.31A)
• Dimensions ( W x D x H ): 171 × 98 × 27 mm
• Max Power Consumption: 3.67 W (220 V/50 Hz no PD connected), 73.24 W (220 V/50 Hz with 63 W PD connected)
• Max Heat Dissipation: 12.48 BTU/h (220 V/50 Hz no PD connected), 249 BTU/h (220 V/50 Hz with 63 W PD connected)
• LED: Power, Link/Act, PoE Status, PoE MAX
• PoE Ports (RJ45): Standard: 802.3 af/at compliant, PoE Ports: Ports 1–8, up to 30 W PoE output per port, Power Supply: 63 W

PERFORMANCE

• Switching Capacity: 1.8 Gbps
• Packet Forwarding Rate: 1.3392 Mpps
• MAC Address Table: 2K
• Jumbo Frame: 1.5 KB

SOFTWARE FEATURES

• Advanced Features: Extend Mode Button (Ports 1–4/ 1–8, Up to 250 m PoE power supply and data transmission), Isolation Mode Button (Ports 1–8), PoE Auto Recovery Button (Ports 1–8), Compatible With IEEE 802.3af/at Compliant PDs, Mac Address Auto-Learning and Auto-Aging, IEEE 802.3x Flow Control, Green Technology
• Transmission Method: Store and Forward


OTHERS

• Package Contents: LS109P, Power Adapter, Installation Guide, Rubber Feet
• Operating Temperature: 0℃~40℃ (32℉~104℉)
• Operating Humidity: 10%~90% non-condensing
