TP-LINK 8-Port Gigabit Desktop Switch with 4-Port PoE+ TL-SG1008P

Dedicated 8-Port Switch with 4-Port PoE+ (64 W Budget) for Numerous Applications

Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 64 W PoE power budget* for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

Intelligent Power Management

When total power consumption exceeds 64 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.

Advanced Functions for Higher Performance

• Qos For Fluent Online Experience: Administrators can designate the priority of traffic based on QoS, for example, to ensure that voice and video applications remain clear and lag-free
• IGMP Snooping, Traffic Optimization for IPTV: IGMP Snooping optimizes multimedia traffic delivery, to ensure a better network experience especially for applications like IPTV

Durable Metal Casing

The interior components of TL-SG1008P are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SG1008P delivers switching performance you can depend on

Specs

HARDWARE FEATURES

• Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m), 100BASE-TX: UTP category 5, 5e cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m), 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m)
• Interface: 8× 10/100/1000 Mbps RJ45 Ports, AUTO Negotiation, AUTO MDI/MDIX
• Fan: No
• Physical Security Lock: Yes
• External Power Supply: External Power Adapter(Output: 53.5VDC / 1.31A)
• Packet Forwarding Rate: 11.904 Mpps
• PoE Ports (RJ45): Standard - 802.3 af/at compliant, PoE Ports - Ports 1 to 4, Power Supply - 64 W
• Mac Address Table: 4K
• Jumbo Frame: 16 KB
• Switching Capacity: 16 Gbps
• Dimensions ( W x D x H ): 171×98×27 mm
• Max Power Consumption:  5.39 W (220/50 Hz no PD connected), 75 W (220/50 Hz with 64 W PD connected)
• Max Heat Dissipation:  18.38 BTU/h (no PD connected), 225.75 BTU/h (with 64 W PD connected)

SOFTWARE FEATURES

• Transfer Method: Store and Forward
• Advanced Functions: Compatible With IEEE 802.3af/at Compliant PDs, IGMP Snooping, Mac Address Auto-Learning And Auto-Aging, IEEE802.3x Flow Control, 802.1p/DSCP QoS

OTHERS

• Package Contents: TL-SG1008P, Power Adapter, Installation Guide
• Operating Temperature: 0℃~40℃ (32℉~104℉)
• Operating Humidity: 10%~90% non-condensing
