HUAWEI eKitEngine Dual Band Indoor Wifi 6 Access Point AP362E

Huawei eKitEngine AP362e is an indoor Wi-Fi 6 (802.11ax) AP. It can simultaneously provide services on the 2.4 GHz (2x2) and 5 GHz (2x2) frequency bands. This AP features high bandwidth, high concurrency, and compact size, facilitating flexible deployment and saving customer investment. Such strengths make the AP a good fit for indoor coverage in SME markets, such as SOHO enterprise offices, small- and medium-sized hospitals, commercial real estate, budget chain hotels, and primary and secondary schools.

Specifications

• Model: AP362e(11ax indoor, 2+2 dual bands, smart antenna)
• Installation Type: Wall, Ceiling, Rail
• Dimensions without packaging (Diameter x depth): 180 mm x 35 mm
• Weight: 0.45kg
• Storage: NAND Flash 256 MB
• Maximum power consumption [W]: 9.4
• Power supply mode: PoE
• Input voltage range [V] PoE: 802.3af
• Ports: GE (RJ45) x 1, 10M/100M/1000M auto-sensing
• Long-term operating temperature: 0°C to 40°C
• Radio number: 2
• Operating frequency band: 2.4GHz, 5GHz
• MIMO spatial streams: Radio 0 (2.4 GHz): 2x2, Radio 1 (5 GHz): 2x2
• Wi-Fi standard: 2.4G: 802.11b/g/n/ax, 5G: 802.11a/n/ac/ac Wave 2/ax
• Radio interface: Built-in smart antennas
• Antenna gain 2.4G: 4 dBi/chain (peak), 2 dBi (combined gain)
• Antenna gain 5G: 5 dBi/chain (peak value), 3 dBi (combined gain)
• Maximum transmit power 2.4G: 17 dBm/chain, 20 dBm (combined power)
• Maximum transmit power 5G: 17 dBm/chain, 20 dBm (combined power)
• DC power supply description: Not supported
• Recommended number of access users: 80
• Number of learnt MAC addresses: 2048
• Number of VLANs: 65
• Number of IPv4 routes: 256
