TP-LINK 10-Port Gigabit Desktop Switch With 8-Port PoE+, LS1210GP

• Full Gigabit Ports: 9× gigabit auto-negotiation RJ45 Ethernet ports and 1× gigabit SFP port provide up to 20 Gbps switching capacity.
• 61 W PoE Budget: Eight gigabit 802.3af/at-compliant PoE+ ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port.
• Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas.
• PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices.
• Traffic Separation for Higher Security: Isolation Mode allows one-click client traffic separation to avoid snooping and tampering, and isolate broadcast storm.
• Plug and Play: Simply plug and play for instant connectivity with no configuration required.
• Silent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses.
• Reliable Hardware Design: Durable metal casing and desktop/wall-mounting design are well-suited for different environments.

Specs

HARDWARE FEATURES

• Interface: 9 × 10/100/1000 Mbps Ports (Ports 1–8 supports PoE+ output), 1× Gigabit SFP Port
• Fan: No
• Network media: 10BASE-T: UTP category 3, 4, 5 cable (Maximum 100m), 100BASE-TX: UTP category 5, 5e cable (Maximum 100m), 1000BASE-T: UTP category 5, 5e, 6 or above cable (Maximum 100m)
• External Power Supply: External Power Adapter (Output: 53.5VDC / 1.31A)
• Dimensions ( W x D x H ): 209 × 126 × 26 mm
• Max Power Consumption: 7.3 W (220 V/50 Hz no PD connected), 79.96 W (220 V/50 Hz with 61 W PD connected)
• Max Heat Dissipation: 24.82 BTU/h (220 V/50 Hz no PD connected), 261.66 BTU/h (220 V/50 Hz with 61 W PD connected)
• PoE Ports (RJ45): Standard: 802.3 af/at compliant, PoE Ports: Ports 1–8, up to 30 W PoE output per port, Power Supply: 61 W

PERFORMANCE

• Switching Capacity: 20 Gbps
• Packet Forwarding Rate: 14.88 Mpps
• MAC Address Table: 4K
• Jumbo Frame: 16 KB

SOFTWARE FEATURES

• Advanced Features: Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data transmission), Isolation Mode Button (Ports 1–8), PoE Auto Recovery Button (Ports 1–8), Compatible With IEEE 802.3af/at Compliant PDs, IEEE 802.3x Flow Control, Green Technology, 802.1p/DSCP QoS, IGMP Snooping
• Transmission Method: Store and Forward


OTHERS

• Package Contents: LS1210GP, Power Adapter, Installation Guide
• Operating Temperature: 0℃~40℃ (32℉~104℉)
• Operating Humidity: 10%~90% non-condensing
