HUAWEI eKitEngine 16 x 10/100/1000BASE-T ports, PoE+, 2 x GE SFP port, Unmanaged Switch S110-16LP2SR

The S100 series fixed Ethernet switches integrate the access and transmission functions to provide reliable access/aggregation and high-quality transmission of services on enterprise networks. The switches are built on an integrated hardware platform, and the hardware system consists of the chassis, power module, fan module, and Switch Control Unit (SCU).

Technical specs

• Dimensions without packaging (H x W x D):  43.6 mm x 442.0 mm x 260.0 mm
• Chassis height [U]: 1
• Chassis material: Metal
• Weight without packaging: 3 kg
• Typical power consumption [W]: 22
• Typical heat dissipation [BTU/hour]: 75.07
• Maximum power consumption [W]: Without PoE: 22 W
• Maximum power consumption with full PoE load: 160 W (PoE: 124 W)
• Maximum heat dissipation [BTU/hour]: Without PoE: 75.07, Full PoE load: 545.94
• Uplink ports: 2 x GE SFP ports
• Downlink ports: 16 x 10/100/1000BASE-T ports (124 W PoE+)
• Working mode: Standard mode, Port isolation, Flow control disabling, Uplink aggregation
• MAC address entry: 8K
• Power supply mode: AC Built-in
• Rated power adapter input voltage: 100–240 V AC; 50/60 Hz
• Fans: None
